FreeScan Trak Nova
Dynamic tracking in a new dimension.
The FreeScan Trak Nova is a wireless, multifunctional 3D measurement system that integrates tracking, laser scanning and photogrammetry in a single compact device.
With its portable design, large measurement volume and high precision, it sets the standard for large-scale industrial measurement – whether in aerospace, mechanical engineering, or the energy and transportation sectors.
An all-in-one system that perfectly combines productivity, mobility and accuracy.
With its portable design, large measurement volume and high precision, it sets the standard for large-scale industrial measurement – whether in aerospace, mechanical engineering, or the energy and transportation sectors.
An all-in-one system that perfectly combines productivity, mobility and accuracy.
Aerospace
Architecture
Automotive Industry
Commercial Good
Education
Prototypes
All-in-one system for the highest demands
The FreeScan Trak Nova combines a portable tracking scanner, the largest FOV handheld laser scanner in its class, and an integrated video photogrammetry module in a fully wireless system. With dual tracking cameras, interchangeable batteries and an integrated computing unit, it delivers maximum efficiency with complete freedom of movement. The system captures large-scale structures as precisely as fine details, making it the ideal solution for extensive inspections, reverse engineering and quality control processes with laboratory-level accuracy – wherever mobility is essential.
0.062 mm (at 12 m³)
Volumetric accuracy
0,025 mm + 0,015 mm/m
Volumetric accuracy with VPG
up to 2,600 × 2,200 mm
Flexible field of view (FOV)
Markerless video photogrammetry
The patented Video Photogrammetry (VPG) system enables markerless operation with automatic real-time marker verification – efficient, time-saving and precise.
Largest field of view in its class
The integrated UE Nova handheld scanner offers the largest field of view (FOV) in its class, combining wide coverage with exceptional detail resolution – ideal for capturing large-scale structures.
Lightweight, wireless and mobile
With integrated wireless modules, interchangeable batteries, and remote control, the FreeScan Trak Nova is designed for maximum freedom of movement and flexibility.
Certified inspection with AI support
The integrated inspection software with AI-assisted feature recognition enables precise full-part inspections – PTB-certified and aligned with industrial quality standards.
Think big, measure precisely
Dynamic tracking redefined
With its innovative real-time tracking technology, the FreeScan Trak Nova captures fine structures and complex shapes with precision, even in tight or hard-to-reach areas. Its compact, wireless design enables flexible operation without restrictions, while the integrated photogrammetry ensures consistently high volumetric accuracy. Whether measuring meter-sized components or intricate machine parts, the Trak Nova delivers fast, reliable results and makes precise large-scale scanning easier than ever before.
FreeScan Trak Nova Webinar
To help you quickly become productive with your new 3D scanner, we offer our quick start course in the form of a webinar (web-based seminar): In just 120 minutes, you'll understand how the 3D scanning software works.
Webinar Process
- Introduction to the functionality and operation of the 3D scanning software
- Overview of the importance of settings
- The right settings for your perfect 3D scan!
- Tips & Tricks
- Troubleshooting – Causes and solutions for the most common problems
Requirements
- Available, operational PC with Windows 7, 8 or Mac OS X with full administrator rights
- Internet access
- Already installed and functional TeamViewer or Microsoft Teams software
The details of the appointment and the webinar software will be discussed after receiving your order.
Support and Service
- Professional consultation
- Custom packages for industrial customers
- On-site training
- Service package with free phone and email support
- Complete solution with 3D printer
- Component optimization via remote maintenance
- Process optimizations
- Customized seminars on-site
- On-site service
Downloads
Technical Specifications
| Volumetric Accuracy | 0.062 mm (12 m³) |
| Volumetric Accuracy with VPG | 0,046 mm + 0,012 mm/m |
| Flexible FOV | Up to 2,600 × 2,200 mm |
| VPG | included |
| FOV Indicator for VPG | included |
| High-Speed Scan | included (50 laser lines) |
| Detailed Scan | included (7 parallel laser lines) |
| Deep Pockets Scan | included (1 laser line) |
| Depth of Field | TE Nova: 380 mm (170 – 550 mm) UE Nova: 2.700 mm (800 – 3.500 mm) |
| Connection | Wireless & Wired mode (fibre optic) |
| Net Weight | TE Nova: 1.2 kg / UE Nova: 1.6 kg |
