EinScan Pro HD
Transform physical objects into digital data – right on your desk.
As a compact and precise desktop device, the EinScan SP V2 impresses with its easy operation and remarkable speed. With automatic calibration and intuitive one-click control, it delivers accurate results in no time – one scan in just one second, a full rotation in 45 seconds. The EinScan SP V2 is the ideal solution for anyone who relies on efficient, highly detailed 3D scanning in a professional environment.
Aerospace
Architecture
Automotive Industry
Commercial Good
Education
Prototypes
Stable and reliable results
Thanks to its flexible scanning range, the EinScan SP V2 is suitable for both small and larger objects. Depending on your requirements, the scan can be performed automatically with the turntable or manually with a tripod – ensuring maximum precision and versatility for every application.
0,05 mm
Scan accuracy
0,17 ~ 0,2 mm
Point distance
< 1s
Scan speed (single shot)
＜45s
Scan speed (one rotation)
200 mm × 150 mm
Scan area
0,045 mm
Color in 3D scanning
Easy reproduction of physical objects with colored textures that enhance the usefulness and realism of the captured 3D models.
Easy Operation, Fast Scanning Speed
One-click scanning without a rigid workflow Automatic calibration without lengthy preparation 1 second for a single scan and 45 seconds for one full rotation
Wide scanning range from small to large
Depending on the size of the object, scanning can be performed using a turntable for automatic scanning or a tripod for manual scanning.
Powerful post-processing functions
The EXScan S software includes functions for hole filling, smoothing, and sharpening meshes, and can readjust data coordinates during post-processing to deliver perfect 3D data for subsequent applications.
EXScan S Software
The scanning software is crucial for smooth scanning with high-quality data. EXScan S makes scanning simple, fast, and delivers excellent results.
The intuitive EXScan S software guides you step by step through the entire scanning process — from calibration to data editing. With five flexible alignment modes and extensive mesh-editing features, scans can be precisely adjusted, refined, and optimized. Adjustable resolutions, plus compatibility with macOS and multiple languages, make the EinScan SP V2 a versatile tool for professionals worldwide.
Downloads
Technical Specifications
| Scan Mode | Fixed Scan with Turntable; Fixed Scan without Turntable | ||||||||
| Align Mode | Manually Align; Feature Align; Turntable Align; Markers Align; Turntable Coded Target Align | ||||||||
| Scan Accuracy | ≤0.05mm | ||||||||
| Minimum Scan Volume | 30mm × 30mm × 30mm | ||||||||
| Maximum Scan Volume | Fixed Scan: 1200mm × 1200mm × 1200mm Turntable: 200mm × 200mm × 200mm | ||||||||
| Singe Scan Range | 200mm × 150mm | ||||||||
| Scan speed of a single shot | ＜1s | ||||||||
| Scan speed of one turn | ＜45s | ||||||||
| Point Distance | 0.17mm ~ 0.2mm | ||||||||
| Color Scan | Supported | ||||||||
| Output Format | OBJ, STL, ASC, PLY, 3MF | ||||||||
| Camera Resolution | 1.3MP | ||||||||
| Light Source | White LED | ||||||||
| Working Distance | 290mm ~ 480mm | ||||||||
| Power Supply | 12V, 3.33A, 40W | ||||||||
| Computer Requirements | OS: Win7, 8, 10 (64bit) CPU: Intel Dual Core i5 or higher; RAM: ＞16GB Graphics Card: Nvidia GTX660 or higher; Video Memory: ＞2GB USB Port: 2.0/ 3.0 | ||||||||
| Device Size | 570mm × 210mm × 210mm | ||||||||
| Weight | 4.2KG |
EinScan Pro HD Webinar
To help you quickly become productive with your new 3D scanner, we offer our quick start course in the form of a webinar (web-based seminar): In just 120 minutes, you'll understand how the 3D scanning software works.
Webinar Process
- Introduction to the functionality and operation of the 3D scanning software
- Overview of the importance of settings
- The right settings for your perfect 3D scan!
- Tips & Tricks
- Troubleshooting – Causes and solutions for the most common problems
Requirements
- Available, operational PC with Windows 7, 8 or Mac OS X with full administrator rights
- Internet access
- Already installed and functional TeamViewer or Microsoft Teams software
The details of the appointment and the webinar software will be discussed after receiving your order.
Support and Service
- Professional consultation
- Custom packages for industrial customers
- On-site training
- Service package with free phone and email support
- Complete solution with 3D printer
- Component optimization via remote maintenance
- Process optimizations
- Customized seminars on-site
- On-site service
